Keeping your HP laptop cool is essential in protecting your company's files. Goodshoot/Goodshoot/Getty Images Hewlett Packard laptops are highly portable, allowing busy professionals to easily transport an entire file cabinet’s worth of data from one job site to another – but as with any laptop, this feature can prove to be its undoing. Because their compact size hinders airflow, HP laptops are highly susceptible to overheating. If your Hewlett Packard’s fan isn’t functioning properly, it’s important to waste no time in replacing it. 1. Shut down your HP laptop, unplug its power cord and disconnect all peripherals. 2. Discharge built-up static electricity from your body by touching an unpainted metal object. 3. Place a soft cloth, such as a towel, on a flat surface. Close your laptop’s display panel and place it upside-down on the cloth. 4. Remove the screw or screws from the battery cover with a Phillips screwdriver. 5. Remove the screws from the hard drive cover with a Phillips screwdriver and lift off the cover.

Unplug the cable that connects the hard drive to the motherboard, if applicable, and slide the drive out of its bay. 6. Remove the screws that secure the CMOS battery and memory module panel. best way to clean hickory hardwood floorsLift off the panel and remove the battery and modules. best way to clean camper awning7. Remove the keyboard cover screws with a Phillips screwdriver. vacuum cleaner price kolkataThese are located in some or all of the following places: the two corners of your laptop’s bottom, directly under the center of the keyboard, in the memory module bay and in the battery compartment. 8. Turn the laptop over and open the display panel. Using a flat-head screwdriver, pry off the upper section of the keyboard flange.

This is the piece that’s closest to the display panel. 9. Remove the upper keyboard screws, which are located over the “F” keys. 10. Lift the keyboard just enough to reveal its ribbon cable connection to the motherboard. If the ribbon cable is secured with a locking flap, lift the flap and gently pull the cable from the motherboard socket. If the connector features locking tabs, depress and hold in the tabs as you pull the cable from the socket. Lift out the keyboard. 11. Locate the LED board socket, which is labeled, on the motherboard. Grasp the connector with your thumb and forefinger and carefully unplug the wire that connects the LED board to the motherboard. Do the same for the video display, power button, webcam, two antenna connections and touchpad, if applicable. 12. Remove the screws from the display panel’s hinges with a Phillips screwdriver. Hold the panel with your free hand to prevent it from falling when the last screw is removed. 13. Lift off the top cover assembly and unplug the cables that connect the USB ports, power jack and audio jacks to the motherboard.

14. Remove the screws from the motherboard with a Phillips screwdriver. Use both hands to carefully lift the motherboard from the laptop case. 15. Remove the screws from your HP’s fan or cooling assembly, unplug its power connector and lift it out of the laptop case. 16. Place your new fan or cooling assembly in the laptop case, tighten its screws and plug in its power connector. 17. Reassemble your HP by following steps 4 through 16 in reverse order. Things Needed Replacement fan or cooling assembly Towel or soft cloth Phillips screwdriver Flat head screwdriver Magnifying glass (optional) Tips Warnings References Inside My Laptop: How to Take Apart HP Pavilion DV5 Laptop Photo Credits Goodshoot/Goodshoot/Getty Images Suggest an Article CorrectionMessage 1 of 9 My laptop has been running quite alot louder and seems to be using the fan more too. I can see quite alot of dust when looking underneath my laptop... And so Im looking for a guide to disassemble my laptop to clear the dust from the fans, its the dv600 series, and the exact model is 6680.

Message 2 of 9 - last edited ony Many times a laptop overheating is directly related to the cooling of the processor. The main culprit is the fan. The fan sucks in air from the bottom and blows it out the side. It will also suck in hair, dust, and other debris. That stuff often gets trapped by the heat sink and over time builds up in a layer which chokes off the cool air going to the processor making the fan work hard/us-en/document/c01657439What I recommend is getting some canned air and blowing out the vents in the side and bottom of the laptop. If after doing this you still have problems with over-heating, and your laptop is in warranty, you can take your laptop to a HP Authorized Service Center and ask them to clean the fan and heatsin/service/ewarranty/warrantyResults.do?admit=109447627+1286541891570+28353475If it is out of warranty, consider searching for the maintenance manual for your specific model, in the manual there are schematics for taking apart the laptop. Cleaning the fan is much easier that removing a motherboard, so don't feel to intimidated by the ide

a. Also you can remove the heatsink and then remove the thermal grease and apply a new layer which also helps alleviate heat related issues.I hope this helps. If you like my advice and it works for you, please thank me by clicking the Kudos Star under my screen name, thanks! ________________________________________________________________________________________________________ I Love Kudos! If you feel my post has helped you please click the White Kudos! Star just below my nameIf you feel my answer has fixed your problem please click 'Mark As Solution' and make it easier for others to find help quickly Message 3 of AM that tip sounds realllly good   where can i buy compressed air though?? Message 4 of AM Just about anywhere, it comes in a can with a long straw attached, much like WD40, anywhere that has computer stuff should have canned air as well. ________________________________________________________________________________________________________ I Love Ku

dos! If you feel my post has helped you please click the White Kudos! Star just below my nameIf you feel my answer has fixed your problem please click 'Mark As Solution' and make it easier for others to find help quickly Message 5 o0 AM I'm highly recommend you to assembly the notebook, clean the heat sink and replace the thermal paste with the good one.Go to local computer store if you cant do it your self. Above steps only effective temporary, the dust will stuck again eventua59 AM Rakhmad wrote:I'm highly recommend you to assembly the notebook, clean the heat sink and replace the thermal paste with the good one.Go to local computer store if you cant do it your self. Above steps only effective temporary, the dust will stuck again eventually.If you read the above steps you would have seen that I told him to have it done under warranty, if applicable, or to disassemble it himself as well as apply fresh thermal paste. ________________________________________________________________________________________________________ I Love

Kudos! If you feel my post has helped you please click the White Kudos! Star just below my nameIf you feel my answer has fixed your problem please click 'Mark As Solution' and make it easier for others to find help qu:20 PM - last edi by Knute said :  "If it is out of warranty, consider searching for the maintenance manual for your specific model, in the manual there are schematics for taking apart the laptop. Cleaning the fan is much easier that removing a motherboard, so don't feel to intimidated by the idea. Also you can remove the heatsink and then remove the thermal grease and apply a new layer which also helps alleviate heat related issues."  ------------------------------------------------------------------------------------------------------------------------------------------------------------------- I am confused, you have to remove the mother board to clean the fan and heat sink fins. You did mention this, but the mother-board still has to be removed for access, or at least on the HDX, dV8, dv7

series.  I am also going to add that if there is this amount of build up in there that compressed air is not going to clean it out as the link may s 8 of 9 ‎0112:58 PM On some models the motherboard must be removed as it is 'upside down' but for most as you know, it's just as easy as taking off the keyboard bezel and keyboard and then unscrewing the screw that holds in the fan.  I don't mean to sound confusing.  Additionally I work with business machines more so than home user based models so forgive me if I am not as familiar with the series you listed. I concur as well that compressed air is not the end-all fix-all for these types of issues. ________________________________________________________________________________________________________ I Love Kudos! If you feel my post has helped you please click the White Kudos! Star just below my nameIf you feel my answer has fixed your problem please click 'Mark As Solution' and make it easier for others to find helpe 9 of 9 ‎0
